Overview of Standard Heat Bank Thermal Stores

to bringing you solutions to all your hot water needs...

Heat Bank Thermal Store Units represent the most comprehensive range of hot water systems around, with models to suit any domestic application, be it electric, gas, solar, or district. Mains Pressure Hot Water at up to 100kW, equivalent to 30 ltr/minute, as standard. Option to increase the hot water output to 200, 300 or even 400kW (120 ltr/min). Units have integral feed & expansion tanks with fitted ball valve as standard. Options to have unit supplied for connection to a separate feed & expansion tank. NEW Manual fill Option, removing the need for an overflow connection. Capacities from 80 to 1000 litres There is no requirement for cold water storage or booster pumps, and all controls that are required for normal operation can be supplied factory fitted and wired. Units are also factory filled and commissioned to ensure correct operation and trouble free installation.

Electric Heat Bank Thermal Store Units use electricity to heat up stored water. As the unit is vented there is no requirement for a trained unvented installer, and as there is no boiler there is no requirement for a gas-qualified installer. The only skills required to install and commission are basic plumbing and wiring. more info...		Indirect Heat Bank Thermal Store Units use an indirect coil to heat up stored water using a remote heat source, such as a gas boiler. The range of options available is staggering, with models to cover every type of primary system, as well as most controls from the major control manufacturers. Some of the options are listed below... Y-Plan, S-Plan, W-Plan, Pump-Plan or GXV-Plan Primaries Standard or High Duty Coils Backup Immersion Heater Solar Coil, optionally with fitted Solar Controls Immersion Heater Controller Standard Foam Insulation or Cased Fitted Balancing Valve / By-Pass Sealed System Controls (Filling Loop, PRV, Gauge, & Vessel) Fitted Programmer Underfloor Heating We can also offer complete packs, including a Heat Bank Thermal Store and a gas boiler, guaranteed to provide the best possible performance as well as superb value for money, with complete boiler-pack systems from as little as £995.

System HBA Low Noise Immersion Heaters 50mm Insulation Thermostatic Temperature Control of hot water Overheat Protection Low Water Level Protection Immersion Heater Controller Cased The HBA provides electrically heated hot water at economy prices, when used with an Economy 7 tariff, or similar. A boost Immersion Heater allows the store to be heated quickly using standard rate electricity. more info... Prices start from as little as £350.

System HB2000 Low Noise Immersion Heaters Central Heating Controls Thermostatic Control of heating Cased as standard Thermostatic Temperature Control of hot water Overheat Protection Low Water Level Protection Room Thermostat supplied loose When used with 18 hour low rate interrupt tariff, or similar, the HB2000 provides electric central heating at economy prices. The store is designed to provide central heating for a continuous 2 hour period, removing the need for electric storage heaters in each room and replacing them with radiators that offer the same level of control as a gas central heating system. more info...
